Let's break this problem down step by step.

The question refers to a cube with an edge length of 10 cm. There are two parts to answer:

(a) Length of $AC$, the diagonal of the base

Since $AC$ is the diagonal of a square face of the cube, we can use the Pythagorean theorem to find its length.
Each side of the square is $10 \, \text{cm}$, so:

$AC = \sqrt{10^2 + 10^2} = \sqrt{100 + 100} = \sqrt{200} = 10\sqrt{2} \, \text{cm}$

Thus, the length of $AC$ is $10\sqrt{2} \, \text{cm}$ (approximately $14.14 \, \text{cm}$).

(b) Angle $\angle DAC$, the angle between a diagonal of the box and a diagonal of the base

We need to find the angle between the space diagonal of the cube (from one corner to the opposite corner) and the diagonal of the base.

1. Length of the space diagonal:
   Using the Pythagorean theorem in three dimensions for the cube: $\text{Space Diagonal} = \sqrt{10^2 + 10^2 + 10^2} = \sqrt{300} = 10\sqrt{3} \, \text{cm}$

2. Angle between space diagonal and base diagonal:
   We are looking for the angle $\theta = \angle DAC$. Using the dot product approach:

   • Length of diagonal of base: $10\sqrt{2} \, \text{cm}$
   • Length of space diagonal: $10\sqrt{3} \, \text{cm}$

   The angle between two vectors $\mathbf{u}$ and $\mathbf{v}$ is given by: $\cos \theta = \frac{\mathbf{u} \cdot \mathbf{v}}{|\mathbf{u}| |\mathbf{v}|}$ Here, $\mathbf{u}$ is the base diagonal (on the $xy$-plane), and $\mathbf{v}$ is the space diagonal. Because the two diagonals share components along the base, the dot product simplifies to:

   $\cos \theta = \frac{10 \times 10 + 10 \times 0}{(10\sqrt{2})(10\sqrt{3})} = \frac{100}{10\sqrt{6}} = \frac{10}{\sqrt{6}}$

   Now simplify: $\cos \theta = \frac{10\sqrt{6}}{6}$ So: $\theta = \cos^{-1} \left( \frac{10\sqrt{6}}{6} \right) \approx 35.26^\circ$

Final Answers:

• (a) Length of $AC$: $10\sqrt{2} \, \text{cm}$ (or $14.14 \, \text{cm}$).
• (b) Angle $\angle DAC$: Approximately $35.26^\circ$.
