Math Problem Statement

Find the derivative and graph of: p(x) = (1 / (σ√2π)) * exp(-1/2 * ((x - μ) / σ)^2)

Solution

The image you uploaded contains the probability density function (PDF) of a normal distribution:

p(x)=1σ2πe12(xμσ)2p(x) = \frac{1}{\sigma \sqrt{2\pi}} e^{-\frac{1}{2} \left(\frac{x - \mu}{\sigma}\right)^2}

To find the derivative of this function p(x)p(x):

We'll differentiate the function with respect to xx. Using the chain rule and recognizing that this is a Gaussian function, we differentiate it step by step:

ddx[1σ2πe12(xμσ)2]\frac{d}{dx} \left[ \frac{1}{\sigma \sqrt{2\pi}} e^{-\frac{1}{2} \left(\frac{x - \mu}{\sigma}\right)^2} \right]

First, treat the constant factor 1σ2π\frac{1}{\sigma \sqrt{2\pi}} as a constant, and then differentiate the exponential term. The derivative of the exponential function eu(x)e^{-u(x)} is eu(x)dudxe^{-u(x)} \cdot \frac{du}{dx}, where u(x)=12(xμσ)2u(x) = \frac{1}{2} \left(\frac{x - \mu}{\sigma}\right)^2.

The result will be:

ddxp(x)=1σ2π(xμσ2)e12(xμσ)2\frac{d}{dx} p(x) = -\frac{1}{\sigma \sqrt{2\pi}} \left( \frac{x - \mu}{\sigma^2} \right) e^{-\frac{1}{2} \left(\frac{x - \mu}{\sigma}\right)^2}

Graph of p(x)p(x):

The graph of this function is a normal distribution (Gaussian curve), which is symmetric about the mean μ\mu with standard deviation σ\sigma.

Do you need further explanation of the steps, or would you like me to generate the graph of the PDF or its derivative?

Ask a new question for Free

By Image

Drop file here or Click Here to upload

Math Problem Analysis

Mathematical Concepts

Calculus
Probability
Gaussian Distribution

Formulas

p(x) = (1 / (σ√2π)) * exp(-1/2 * ((x - μ) / σ)^2)
d/dx p(x) = - (1 / (σ√2π)) * ((x - μ) / σ^2) * exp(-1/2 * ((x - μ) / σ)^2)

Theorems

Chain Rule
Gaussian Function

Suitable Grade Level

College
