From the image and the problem written in Persian, you are asking to calculate the equivalent resistance of the circuit between points $A$ and $B$.

Circuit Details:

• There are three resistors:
  1. $R = 15 \, \Omega$
  2. $R = 11 \, \Omega$
  3. $R = 17 \, \Omega$
• Based on the diagram:
  • $R = 15 \, \Omega$ and $R = 11 \, \Omega$ are in parallel.
  • The equivalent resistance of the parallel combination is in series with $R = 17 \, \Omega$.

Steps to Solve:

Step 1: Parallel Combination

The formula for two resistors in parallel is: $R_{\text{parallel}} = \frac{R_1 \cdot R_2}{R_1 + R_2}$ Here: $R_{\text{parallel}} = \frac{15 \cdot 11}{15 + 11} = \frac{165}{26} \approx 6.35 \, \Omega$

Step 2: Total Resistance

The equivalent resistance $R_{\text{eq}}$ is the sum of $R_{\text{parallel}}$ and $R = 17 \, \Omega$: $R_{\text{eq}} = R_{\text{parallel}} + 17 = 6.35 + 17 = 23.35 \, \Omega$

Final Answer:

The equivalent resistance between points $A$ and $B$ is approximately: $R_{\text{eq}} \approx 23.35 \, \Omega$

Would you like more detailed steps or further clarification?
